Description

The Gens Ace G-Tech 2200mAh 4S 14.8V 45C LiPo Battery combines dependable performance with a versatile universal connector system supporting XT60, EC3 and Deans-style connections.

Its 45C continuous discharge rating and 90C maximum burst rating provide responsive power for compatible electric aircraft, EDF jets, FPV models and other demanding RC applications. Stable cell-stacking technology and closely matched cells help provide consistent voltage and reliable performance throughout operation.

The compact soft-case battery includes Gens Ace’s 1-to-3 universal connector system, providing greater flexibility when using the pack across models with different power connections.

Its G-Tech balance connector allows compatible Gens Ace smart chargers to automatically identify the battery and select the appropriate charging parameters. Conventional LiPo balance chargers may also be used with the correct lead and manually selected settings.

Key Features

  • 2200mAh capacity

  • Standard 4S 14.8V LiPo chemistry

  • 45C continuous discharge rating

  • 90C maximum burst discharge rating

  • Universal connector system

  • Supports XT60, EC3 and Deans-style connections

  • Compact soft-case construction

  • G-Tech smart balance connector

  • Automatic identification with compatible G-Tech chargers

  • Suitable for compatible electric aircraft and EDF models

Specifications

  • Brand: Gens Ace

  • Series: Air Classic

  • Product code: GEA224S45T3GT

  • Manufacturer part number: GA-B-45C-2200-4S1P-1TO3-GT

  • Barcode: 889551117234

  • Battery chemistry: Lithium Polymer

  • Capacity: 2200mAh

  • Configuration: 4S1P

  • Cell count: 4 cells

  • Nominal voltage: 14.8V

  • Fully charged voltage: 16.8V

  • Continuous discharge rating: 45C

  • Maximum burst discharge rating: 90C

  • Connector options: XT60, EC3 and Deans-style

  • Balance connector: G-Tech 5-pin

  • Case type: Soft case

  • Dimensions: Approximately 108 × 34 × 30mm

  • Weight: Approximately 234g

  • Power-wire gauge: 12AWG

  • Power-wire length: Approximately 120mm

  • Balance-wire length: Approximately 65mm

Suitable Applications

Subject to battery-compartment, connector and power-system compatibility:

  • 3D HobbyShop 48-inch foam aircraft

  • 64mm EDF jets

  • Selected 70mm EDF jets

  • Compatible F-16 and F-15 models

  • FMS 980mm P-39 Racing

  • FMS 980mm P-40B Flying Tiger

  • FMS 980mm P-47 Razorback

  • Compatible FPV aircraft

  • Other RC models requiring a 4S 2200mAh battery

Package Contents

  • 1 × Gens Ace G-Tech 2200mAh 4S 14.8V 45C LiPo Battery

  • 1 × Universal 1-to-3 connector/adaptor set for XT60, EC3 and Deans-style connections

Important Compatibility Information

This is a standard 4S LiPo battery, not a LiHV battery. Charge only with a suitable LiPo balance charger configured for a standard 4S battery, with a maximum fully charged voltage of 16.8V.

Only one main connector option should be used at a time. Confirm that the selected connection is secure and correctly matched to the model. Also verify that the model’s ESC, motor and other electronics support 4S power before installation.
