UDIRC INKFISH UDI-023-PRO 14" Brushless Jet Boat RTR

The UDIRC INKFISH UDI-023-PRO is a unique high-performance RC personal watercraft featuring brushless power, jet-pump propulsion and a self-righting shallow-V hull.

Unlike a conventional RC boat with an exposed propeller and rudder, the INKFISH uses an enclosed water-jet propulsion system. Water is drawn through the bottom of the hull and expelled through the rear steering nozzle, providing propulsion and steering while keeping the propeller safely enclosed.

Power comes from a 2812 3500KV water-cooled brushless motor, providing the PRO version with approximately 20km/h top speed.

With its realistic personal-watercraft styling, controllable navigation lights, built-in gyro, self-righting system and included 7.4V 2000mAh rechargeable battery, the INKFISH is a fun and distinctive addition to any RC boat collection.

3500KV Brushless Power

The PRO version of the INKFISH is equipped with a 2812 3500KV brushless motor.

Compared with the standard brushed UDI023, the brushless system provides improved performance, efficiency and acceleration.

The motor itself is water cooled to help control operating temperature during high-speed use.

Water-Cooled Marine ESC

The brushless motor is paired with a dedicated water-cooled marine ESC.

The ESC features a waterproof design with integrated cooling and heat dissipation, along with protection functions including:

• Low-voltage protection
• Over-temperature protection
• Locked-motor protection

This provides the electronics with additional protection during demanding operation on the water.

Jet-Pump Propulsion

One of the biggest differences between the INKFISH and a conventional RC boat is its jet-pump propulsion system.

Rather than using an exposed propeller behind the hull, the impeller is enclosed within the jet-pump assembly.

This provides several advantages, including reduced risk of the propeller becoming caught on underwater obstacles and improved suitability for operating in relatively shallow water.

The jet nozzle also provides directional control, giving the INKFISH its realistic personal-watercraft handling characteristics.

Shallow-V ABS Hull

The INKFISH features a strong 362mm shallow-V ABS hull.

The shallow-draft design works particularly well with the enclosed jet-pump system because no conventional propeller or drive shaft extends below the rear of the hull.

UDIRC specifies a 32-degree deadrise angle, providing a good combination of stability and manoeuvrability.

Self-Righting System

Capsizing isn't necessarily the end of your run.

The UDI-023-PRO incorporates a one-button self-righting function. When conditions allow, pressing the designated transmitter function allows the watercraft to return itself to the upright position.

This is a particularly useful feature when operating away from the shoreline.

Built-In Gyro Stability

The PRO version features a 4-channel receiver with a built-in gyroscope.

The gyro helps improve directional stability by providing automatic steering corrections when required, making the INKFISH easier to control during acceleration and high-speed operation.

Controllable Navigation Lights

Functional navigation lighting adds to the realistic appearance of the INKFISH.

The lighting can be controlled from the transmitter, making the model particularly impressive when running in lower-light conditions.

One-Click Acceleration

The transmitter incorporates a one-click acceleration function, providing quick access to increased performance.

This works alongside the proportional throttle system to make the INKFISH both easy and entertaining to operate.

Low Battery & Out-of-Range Alarms

The 2.4GHz radio system features useful warning functions for:

• Low battery voltage
• Out-of-range conditions

These provide additional warning to bring the watercraft back towards shore before battery voltage or radio range becomes a problem.

7.4V 2000mAh Battery Included

The UDI-023-PRO includes a 7.4V 2000mAh rechargeable lithium battery.

UDIRC specifies approximately 10 minutes of running time for the PRO version, depending on throttle use and operating conditions.

A USB 2-cell balancing charger is also included.

2.4GHz Radio System

The supplied UA37 2.4GHz radio system provides proportional control and an advertised operating range of approximately 100 metres under suitable conditions.

The transmitter requires 4 × AAA batteries, which are not included.

Key Features

• UDIRC INKFISH UDI-023-PRO
• 14" / 362mm RC jet boat
• PRO brushless version
• 2812 3500KV brushless motor
• Water-cooled motor
• Water-cooled marine ESC
• Jet-pump propulsion
• Enclosed impeller system
• Shallow-draft design
• Shallow-V ABS hull
• Approximately 20km/h top speed
• Self-righting function
• Built-in gyro stability system
• 4-channel receiver
• High-torque waterproof 9g steering servo
• Controllable navigation lights
• Anti-collision rubber strip
• One-click acceleration
• Low battery alarm
• Out-of-range alarm
• Forward and reverse
• Left and right steering
• 2.4GHz UA37 radio system
• Approximately 100m radio range
• 7.4V 2000mAh battery included
• USB balancing charger included
• Ready-to-Run

Specifications

• Brand: UDIRC / UDI RC
• Model: INKFISH UDI023PRO
• Product Code: UDI-023-PRO
• Type: Brushless RC Jet Boat / Personal Watercraft
• Hull Type: Shallow-V
• Hull Material: High-Strength ABS
• Propulsion: Enclosed Jet Pump
• Motor: 2812 3500KV Brushless
• Motor Cooling: Water Cooled
• Motor Diameter: 28mm
• Motor Length: 21mm
• Motor Weight: 49.4g
• Motor Connectors: 3.5mm Bullet
• ESC: Water-Cooled Marine Brushless ESC
• Receiver: 4-Channel with Built-In Gyro
• Steering Servo: 9g Waterproof
• Battery: 7.4V 2000mAh Rechargeable Lithium
• Charger: USB 2S Balanced Charger
• Charger Output: 7.4V / 1500mA Max
• Charging Time: Approximately 230 Minutes
• Top Speed: Approximately 20km/h
• Runtime: Approximately 10 Minutes
• Length: 362mm
• Width / Beam: 127mm
• Height: 110mm
• Weight: Approximately 659g
• Deadrise: 32°
• Radio: UA37 2.4GHz
• Control Range: Approximately 100m
• Self-Righting: Yes
• Recommended Age: 14+

What's Included

• UDIRC INKFISH UDI-023-PRO
• 2812 3500KV brushless motor – installed
• Water-cooled brushless ESC – installed
• 4-channel gyro receiver – installed
• Waterproof steering servo – installed
• UA37 2.4GHz transmitter
• 7.4V 2000mAh rechargeable battery
• USB balancing charger
• Maintenance tools
• User manual

Required to Run

You will need:

• 4 × AAA batteries for the transmitter

The main boat battery and charger are included.

Brushless Jet-Pump Fun

The UDIRC INKFISH UDI-023-PRO stands out from conventional RC boats thanks to its realistic jet-pump propulsion system.

The enclosed propulsion system, shallow-draft hull and self-righting capability make it particularly fun for exploring areas where a traditional exposed-propeller RC boat may be less suitable.

Add the 3500KV brushless motor, water cooling, gyro stability, controllable lights and complete RTR package, and the UDI-023-PRO offers a very different RC boating experience straight from the box.
