Product Information

FH5 RF mode is higher resolution than former FH4 RF mode. Also, MT-R installed SUR (SANWA ULTRA RESPONSE) Mode which is faster mode than SSR (SANWA SUPER RESPONSE) mode which was installed in MT-S. Combination with FH5 RF mode and SUR mode will give great smooth feeling. Compatible receivers are RX-491, RX492, RX-492i RX-493, and RX-493i. (FH3 and FH4 compatible receivers as RX-38*, 45*, 46*, 47*, and 48* cannot be used for MT-R) *RX-492i and RX493i can be used with MT-R. But MT-R does not have indicator function, so indicator function does not work with MT-R.

Product Features:

UNUSUAL ABILITY IN THE CLASS

1 SETUP WIZARD FOR EASY SETTING

CAR TYPE(9 MODEL TYPES) CAN BE SET EASILY.

2 SSL (SANWA SYNCHRONIZED LINK)-COMPATIBLE

The compatible equipment can be set by transmitter through CODE AUX functions.
Compatible equipment: Super Vortex Gen2 series, SSGS-02, PGS servo series

3 LIGHT BODY (363g)

EASY OPERATION FOR CHILDREN

MIDDLE CLASS (ENTRY LEVEL)

System Features:

• WHITE LED BACK LIGHT
• LARGE FULL-DOT LCD MONITOR(128x64dot)
• ST TH TENSION ADJUSTMENT
• ADJUSTABLE TRIGGER

Other Information:

[SSL(SANWA SYNCHRONIZES LINK) SYSTEM]

SANWA SSL SYSTEM
When used with compatible RX-491, 492, 492i, 493, 493i, Super Vortex Gen2 series, SGS-02, and PGS servo series, the setting of ESC, Gyro, and Servos etc. by Transmitter is available through SSL functions while driving.
Since the setting can be done without the stop of the car, the detailed adjustment in accordance with Race conditions is available without interruption of Intervals and the change of machine conditions.

[RESPONSE OF TELEMETRY SYSTEM]

It is often said that telemetry systems reduce response speed. However, SANWA Original Data Processing and Algorithm Design make Telemetry possible without response speed reduction. Our Excellent Telemetry System has no response speed reduction.
With our telemetry system, the precious race data will help the next race setting and driving.

[RESPONSE MODE]

Please do not use Analog Servo for SHR mode, SSR mode, or SUR mode. If an analog servo is used for SHR mode, SSR mode, or SUR mode, the servo will be broken and will not work. Digital servo (PGS series, SRG series, Digital ERG series, SDX series) can be used both for NOR mode and SHR mode.
SSR mode can be used only by SRG servo series and PGS servo series. In SHR or SSR mode, BL-RACER, BL-FORCE, BL-SPORT, F2000, F2200, F3000, F3300, SBL-01, SBL-02, and SBL-03CR do not work. Please use NOR mode for the above ESC.
SV-08, HV-10, HV-12, F2500 can work by NOR/SHR MODE. SUR mode can be used only by Super Vortex Gen2, Gen2 PRO, and PGS servo series.
