ESC Features

• Wide 2s-4s input voltage range for powering a wide variety of applications
• Sensored, Sensorless and SmartSense Running Modes
• Brushless and brushed motor operation
• Powerful Integrated 8A Peak Adjustable BEC (5.25V-8.0V)
• Data logging capability to capture and record performance data from your vehicle
• Auxiliary wire functionality for "on-the-fly" adjustments using your transmitter
• Compatible with S.BUS2 Telemetry Link and Futaba T4PX and T7PX transmitters
• Convenient transmitter programming for six common adjustable settings including cutoff voltage and drag brake
• Dial in ESC settings, update ESC firmware and view data logs with Castle Link USB programming kit
• Optional smartphone-based programming, firmware updates and data log viewing with the B-LINK Bluetooth Adapter (sold separately) and Castle Link software for iOS or Android (free download)
• ESC is housed in a rugged CNC aluminum case and potted in waterproof epoxy to protect the electronics and promote efficient heat transfer
• Waterproof design for all weather conditions
• Factory equipped thermally controlled (and removable) 30mm cooling fan
• 12 AWG high strand count silicone coated copper power wires
• Integrated Capacitors and 4mm Bullet Connectors add durability in extreme conditions
• Audible Alerts and LED Alerts for easy diagnoses of common issues such as motor-over-temperature and low-voltage cutoff

Motor Features

• Input Voltage range: 2s-6s LiPo
• Redesigned rotor and stator assemblies.
• Reduced magnetic cogging, producing less residual drag brake.
• Increased efficiency, resulting in lower temperatures and longer run times.
• Smoother start-up, reducing cogging or stuttering when starting from a stop.
• Rebuildable design allows replacement of front end bell/bearing assembly or rotor/shaft assembly.
• High-Strength Kevlar Wrap and 180C Grade Neodymium Sintered Magnets
• Oversized NMB Bearings and High-Temperature, High-Purity Copper Windings
• Castle 10 AWG, High-Strand-Count Silicone-Insulated Wire with 4.0mm Bullet Connectors
• High-Performance 0.2mm Steel Lamination Stacked Stator
• Oversized, low-resistance, gold-plated solder tabs
• Sensor board with High Quality Temperature-Stabilized Sensors
• T6 Aluminum CNC Machines Front/Rear End bell
• Backed by Castle Creations' 1-YEAR WARRANTY
