Case material: plastic
case size: 186*103*209mm
weight: 1610g

Display

Display type: 2x16 lcd
display backlight: blue

Power

Dc input voltage: 11-18v
ac input voltage: 100-240v 50/60hz
charge wattage: 100w x 4
discharge wattage: 10w

Battery

Battery types/cells:
lipo/lihv/life/liion: 1-6s
nimh/nicd: 1-15s
pb: 2-20v


battery capacity range:
nimh/nicd:100-50000mah
lipo/liion/life/lihv:100-50000mah
pb: 100-50000mah

Charge and discharge

Charge voltage

Nimh/nicd: delta peak detection

Lipo: 4. 18-4. 25v/s
life: 3. 58-3. 7v/s
pb: 1. 8-2. 0v/s

Liion: 4. 08-4. 2v/s
lihv: 4. 25-4. 35v/s

Discharge cut-off voltage

Nimh/nicd: 0. 1-1. 1v/s

Lipo:3. 0-3. 3v/s
life:2. 6-2. 9v/s

Liion: 2. 9-3. 2v/s
lihv: 3. 1-3. 4v/s

charge voltage range: 0. 1-26. 1v/cell
charge current: 0. 1a-12. 0a
discharge current: 0. 1a-2. 0a
balance current: 500ma max.
safety timer: 1 â½âž720min and; off(default: 120mins)

Working and storage

Operating temperature: 0 ℠âƒ-40 ℠âƒ
working humidity: 0%-75%
storage temperature: -10 ℠âƒ-70 ℠âƒ
storage humidity: 0%-75%
