Description
Like every component in the spektrum smart ecosystem, firma smart escs combine "plug-and-play" simplicity with the ability to communicate with other smart electronics, creating the best-performing rc system for your vehicle
Firma smart escs do much more than regulate power. They function like a virtual engineer inside your model, providing a direct path to the vital operating data you need to reach peak performance. Firma smart escs give you more confidence that your electronics are all operating at their best
With firma smart escs, you'll be better connected to your vehicle than ever without installing extra components that work independently. You won't need additional wires, modules, or links. A firma electronic speed control provides a one-wire solution for obtaining telemetry data such as rpm, temperature, battery voltage, and capacity
Firma escs gather the data and send it to your transmitter in real-time instead of storing it for an after-run study. You can adjust settings as needed to boost performance on the go. The firma smart single-wire telemetry solution has been tested for quality and performance by the best brands in rc. Their verdict? smart technology is both simpler and superior!
Firma escs feature ic series battery connectors. The ic series of connectors are designed from the ground up to provide a more solid connection, higher heat resistance, and effortless installation. When used with an ic3 or ic5 connector-equipped spektrum smart battery, the esc can receive and transmit battery telemetry data. Ec3 and ec5 are also compatible with firma escs for basic operation and esc telemetry.
The all-weather, waterproof design of spektrum firma smart escs allows them to perform in nearly any terrain under almost any conditions. Firma escs keep you going through dust, gravel, snow, and water.
No need to connect multiple wires, sensors, modules, and links. With firma escs, simple one-wire telemetry transmits a wide range of data directly to your transmitter in real-time, including rpm, voltage, temperature, balance, capacity, and speed. *
*see the compatibility chart for more information.
When used with a spektrum smart lipo battery, your firma esc provides battery telemetry that's automatically transmitted to your compatible spektrum radio in real-time. On your transmitter screen, you'll be presented with helpful information such as the number of cycles, battery percentage, individual cell voltage, and more!
Multiple programming options are available. Button programming can be used with nothing more needed. Using the smart firma esc programming box, you can easily change settings at the track to suit driving conditions. An easy-to-use smart link usb updating and pc programmer app is also available.
When used with spektrum transmitters with on-screen telemetry, the esc can also be programmed easily through the textgen on-screen prompts.
The firma escs' 32-bit m4 processor produces a higher resolution signal input and more accurate motor output
what's in the box?
(1) spektrum firma smart esc
(1) spektrum smart sticker sheet
(1) product manual
- smart all-in-one telemetry
- fast, powerful 32-bit arm m4 processor
- waterproof*
- programming optimized for lmt 2. 0 trick modes/freestyle modes
- multiple options for easy programming:
- button programming
- smart esc programming box
- smartlink usb updating and programmer application
- textgen interface
- multi-point protection:
- over-current protection
- automatic lipo low-voltage cutoff
- thermal protection
- failsafe protection
- developed and designed by spektrum engineers in partnership with the industry's leading esc manufacturer
- compatible with the losi lmt 2. 0
- high current adjustable bec (6v or 7. 4v @ 4 amps)
- compact for easy installation in most applications
- ready to install â no soldering required
- rugged plastic case with mounting tabs
- aluminum heat sink for high efficiency
- cooling fan
- adjustable high-power bec
- firmware updatable through the smart esc programming box
- high heat-resistant ic connectors, backward compatible with ec connectors
- limited 1-year warranty
