There are two types of operation of the ks-01. Please refer to the following to configure the transmitter side to determine which operation you want to use

normal mode
use the switch to turn the igniter on and off.
how to set it up
decide which channel and toggle switch to turn the igniter on or off. Use the transmitter's endpoint function to set the operating volume to "100%" for both left and right sides. Turn on the ks-01. Operate the toggle switch on the transmitter side to check the direction of operation. If you want to reverse the on/off direction, use the reverse function on the transmitter to change it

safe mode
two switch operations within 0. 5 seconds turn the igniter on and off. (prevention of erroneous operation)
how to set it up
decide which channel and toggle switch to turn the igniter on or off. Use the transmitter's endpoint function to set the operating volume to "50%" for both left and right sides. Turn on the ks-01. Operate the toggle switch on the transmitter side to check the direction of operation. If you want to reverse the on/off direction, use the reverse function on the transmitter to change it

precautions
* if the neutral is shifted significantly with sub-trim, etc. , it may not be possible to turn it on / off normally, so please set the sub-trim to "0".
* if the toggle switch is set to on after the transmitter is turned on, it will not turn on unless it is turned off.
* after changing the value of the transmitter endpoint, be sure to turn the ks-01 off and on again.
