ARRMA MOJAVE 4S BLX V2 1/8 4WD RTR Brushless Desert Truck

The ARRMA MOJAVE 4S BLX V2 is a large 1/8 scale 4WD brushless desert truck designed for high-speed off-road driving, big jumps, rough terrain and serious RC bashing.

Built around ARRMA's proven MOJAVE desert-racing platform, the MOJAVE 4S combines realistic desert truck styling with a powerful Spektrum brushless system, independent suspension and a durable 4WD drivetrain.

The ARA4404V2 is powered by a Spektrum FIRMA brushless system and is capable of speeds of 50+ mph / 80+ km/h with an appropriate 4S LiPo battery and suitable gearing. ARRMA's official specifications list the MOJAVE 4S platform as a 1/8 scale, mid-motor, 4WD desert truck.

Spektrum 4S Brushless Power

The MOJAVE 4S V2 is equipped with a Spektrum FIRMA 120A Smart waterproof ESC and Spektrum FIRMA 3668 2400Kv brushless motor.

The 4S brushless power system provides strong acceleration and plenty of torque for high-speed desert driving, jumps and aggressive bashing.

The Smart ESC provides telemetry compatibility when used with suitable Spektrum Smart equipment and features programmable settings for tuning throttle response and braking performance.

The system is compatible with:

• 3S LiPo batteries
• 4S LiPo batteries
• IC5 or EC5 connectors

50+ MPH Performance

With a suitable 4S LiPo battery, the MOJAVE 4S can reach speeds of 50+ mph / 80+ km/h under suitable conditions.

The combination of the mid-motor layout, long wheelbase, large tyres and independent suspension provides excellent stability when driving at speed.

Mid-Motor 4WD Layout

The MOJAVE 4S uses a mid-motor 4WD configuration.

Positioning the motor towards the centre of the chassis helps provide balanced weight distribution and improved handling.

The 4WD drivetrain delivers power to all four wheels, providing strong traction on dirt, grass, gravel and other suitable off-road surfaces.

Heavy-Duty Drivetrain

The drivetrain is designed to withstand the torque generated by the 4S brushless system.

The vehicle features durable metal-geared differentials, strong driveshafts and a robust composite drivetrain system.

A 0.8 MOD gear pitch provides an excellent balance between strength and efficient power transfer.

Independent Suspension

The MOJAVE features fully independent suspension designed specifically for high-speed off-road driving.

Long-travel suspension allows the truck to absorb bumps, jumps and rough terrain while maintaining traction.

The vehicle is equipped with oil-filled aluminium-body coil-over shocks, providing adjustable damping for different driving conditions.

Desert Truck Styling

The MOJAVE 4S combines realistic desert-race-truck styling with functional protection.

The detailed body is supported by a strong roll cage and features aggressive desert-truck graphics.

Front and rear bumpers help protect the chassis and body during impacts, while side protection helps keep the body and chassis protected during hard bashing.

dBoots Multi-Terrain Tyres

The MOJAVE 4S is equipped with large dBoots multi-terrain tyres designed for off-road performance.

The aggressive tread provides traction across dirt, gravel, grass and other suitable surfaces.

The wheels use 17 mm hexes, making them easy to remove and providing a strong connection to the drivetrain.

Spektrum SLT3 Radio System

The MOJAVE 4S V2 includes a Spektrum SLT3 3-channel 2.4GHz transmitter and Spektrum SR315 receiver.

The SLT3 transmitter includes adjustable throttle limiting, allowing drivers to select reduced power settings before progressing to full performance.

Throttle settings can be adjusted to 50%, 75% or 100%, making the truck easier to control for newer drivers.

High-Torque Spektrum S662 Servo

The V2 is equipped with a Spektrum S662 digital metal-geared steering servo.

The S662 provides increased torque and improved durability compared with the previous steering servo, making it well suited to the large 1/8 scale MOJAVE platform.

Key Features

• 1/8 scale ARRMA MOJAVE 4S BLX V2
• ARA4404V2 platform
• 4WD brushless desert truck
• Ready-to-Run
• Mid-motor configuration
• Spektrum FIRMA 3668 2400Kv brushless motor
• Spektrum FIRMA 120A Smart waterproof ESC
• 3S and 4S LiPo compatible
• 50+ mph / 80+ km/h potential top speed
• Spektrum SLT3 3-channel transmitter
• Spektrum SR315 receiver
• Spektrum S662 metal-geared steering servo
• Independent suspension
• Aluminium-body oil-filled coil-over shocks
• Durable 4WD drivetrain
• Metal-geared differentials
• 0.8 MOD gear pitch
• dBoots multi-terrain tyres
• 17 mm wheel hexes
• Mid-motor chassis layout
• Realistic desert truck body
• Protective roll cage
• Front and rear bumpers
• IC5/EC5 compatible
• Waterproof electronics

Specifications

• Brand: ARRMA
• Model: MOJAVE 4S BLX V2
• Part Number: ARA4404V2
• Scale: 1/8
• Vehicle Type: Desert Truck
• Drive: 4WD
• Motor Configuration: Mid Motor
• Power Type: Electric Brushless
• Completion Level: Ready-to-Run
• Power System: 4S
• Motor: Spektrum FIRMA 3668 2400Kv
• Motor Type: Brushless
• ESC: Spektrum FIRMA 120A Smart Waterproof
• Radio: Spektrum SLT3 3-Channel 2.4GHz
• Receiver: Spektrum SR315
• Steering Servo: Spektrum S662 Metal Gear Digital
• Differentials: Gear Differentials
• Gear Pitch: 0.8 MOD
• Drivetrain: 4WD
• Suspension: Independent
• Shock Type: Aluminium Body, Oil-Filled Coil-Over
• Front Track: 326 mm
• Rear Track: 326 mm
• Length: 638 mm
• Wheelbase: 380 mm
• Ride Height: 45 mm
• Height: 242 mm
• Top Speed: 50+ mph / 80+ km/h
• Battery Compatibility: 3S or 4S LiPo
• Battery Connector: IC5 / EC5
• Wheel Hex: 17 mm
• Water Resistant: Yes
• Surface: Off-Road

ARRMA's official MOJAVE 4S specifications confirm the 638 mm length, 380 mm wheelbase, 45 mm ride height, 326 mm front and rear width and 50+ mph / 80+ km/h potential speed.

Battery & Charger Required

The MOJAVE 4S V2 is supplied Ready-to-Run, but battery and charger are sold separately.

Compatible batteries include:

• 1 × 3S LiPo
• 1 × 4S LiPo
• 2 × 2S LiPo, depending on the specific battery configuration and supplied wiring

ARRMA specifies a minimum 5000mAh 50C LiPo for the platform. The battery tray accommodates packs up to approximately 163 × 51 × 48 mm for the MOJAVE 4S configuration.

For maximum performance, a suitable 4S LiPo battery is recommended.

What's Included

• ARRMA MOJAVE 4S BLX 4WD 1/8 Desert Truck RTR
• Spektrum FIRMA 3668 2400Kv Brushless Motor
• Spektrum FIRMA 120A Smart Waterproof ESC
• Spektrum S662 Metal-Geared Steering Servo
• Spektrum SLT3 3-Channel 2.4GHz Transmitter
• Spektrum SR315 Receiver
• dBoots Multi-Terrain Tyres
• Factory-finished desert truck body
• Instruction manual

Built for High-Speed Desert Bashing

The ARRMA MOJAVE 4S BLX V2 brings large-scale desert truck performance into a package that is powerful, durable and easy to drive.

Its mid-motor layout, 4WD drivetrain, independent suspension, long-travel shocks and large off-road tyres make it particularly well suited to high-speed dirt driving, jumps and rough terrain.

The Spektrum 4S brushless system provides plenty of power for experienced drivers, while adjustable throttle limiting makes the MOJAVE easier for newer drivers to learn.

Please note: This is a high-performance brushless RC vehicle. Always operate in a large, open and suitable area away from people, traffic and obstacles. Follow all manufacturer instructions regarding LiPo batteries, charging and safe operation.
